Controls Guide

This guide describes the available radiator controls and explains their functions.

It is useful for using the radiator in Manual Mode after connecting it to the IRSAP NOW App.

Controls functions

	Power Button
Turn the display On/Off Activate/Deactivate Standby Activate/Deactivate Anti-Freeze Mode Radiator connection status

	Setpoint Buttons
Increase the set temperature Decrease the set temperature

	Home Button
Detected room temperature display Active schedule display Set temperature display Display Off

Meaning of the LEDs

	Power Button
Radiator connected
Blu/Red	Radiator connected + Anti-Freeze active
Red	Radiator not connected + Anti-Freeze active

	Programmed Mode LED
Red	Programmed Mode ON
Off	Programmed Mode OFF

	Manual Mode LED
Red	Manual Mode ON
Off	Manual Mode OFF

	Temporary Manual Mode LED
Red	Temporary Manual ON
Off	Temporary Manual Mode OFF

*LEDs light up after the display is switched on and remain visible for about 5 seconds.

Tips or Troubleshooting

Here you can find answers to the most frequently asked questions:

• How do I activate Anti-Freeze Mode?
• How do I activate Standby Mode?
• How do I schedule the radiator?
• How do I change the desired temperature?


Visit the Operation section to discover additional functions yavaible in the app.
